Stand-on concrete laser levelling machine with 24 HP Honda GX-690 engine, Topcon laser and 2500 mm paving width, laying 30-200 mm thickness with independent suspension and centre rotation.
Price range ₹30,00,000 – ₹33,00,000 Ex-works Delhi. Final price depends on configuration.
Not sure this is the right size?
Tell us the material, the area and the specification you have to meet. We will tell you which machine fits — and which one is more than you need.
The LS-400 is the stand-on version of our concrete laser levelling range, and the step up from the LS-325 when the pour area is large enough that walking the machine stops making sense. The operator rides the machine, which cuts fatigue over a long pour and keeps the screed head moving at a steady rate.
It paves 2500 mm wide against the LS-325 working length of 2.6 m, at a thickness of 30 to 200 mm, driven by a 24 HP Honda GX-690 petrol engine with a 35 litre fuel tank for extended runs. A Topcon laser generator drives the levelling, with laser scanning and a high-sensitivity control system that handles both flat surfaces and graded floors.
Levelling is by independent suspension with centre rotation, which lets the screed head follow the slab rather than the machine frame. Drive is hydraulic through heavy-duty tyres, with stepless forward and reverse at 0-2.5 km/h and switch-controlled turning. Operating weight is 865 kg.
Supplied, commissioned and serviced by Topall Impex, Delhi, exclusive India partner for Dynamic.
The LS-400 places 2500 mm wide at 30 to 200 mm thickness from a 24 HP Honda GX-690, with independent suspension and centre rotation. The LS-325 covers 2.6 m working length walk behind at a third of the price.
The LS-400 is the right machine when you are pouring open industrial slabs in large panels and the constraint is how fast concrete can be placed and struck off. On floors broken up by columns, bays and access restrictions, the walk behind machine will finish more square metres in a day despite being smaller.
Placing range is 30 to 200 mm, which covers most industrial floor and topping work in a single pass. Laser control handles flat and sloped floors, with the scanning system and high sensitivity push rod holding the plane across the panel rather than only at the screed rails.
This is a machine for contractors running industrial flooring as a continuous line of work. At 865 kg it needs transport and site access planned before it arrives, and a 35 litre fuel tank means it is built to run all day rather than in bursts.
Delivery, site commissioning, laser calibration and operator training on both flat and slope work. Blades, hydraulic parts and Topcon consumables are stocked in Delhi.
| Specification | LS-400 |
|---|---|
| Engine Model | Honda GX-690 |
| Engine Type | Petrol, V-cylinder engine, air cooling |
| Engine Power (Hp) | 24 |
| Laser Generator | Topcon |
| Lubricating Oil (L) | 2 |
| Fuel Tank Capacity (L) | 35 |
| Type of Leveling | Independent suspension, center rotation |
| Paving Width (mm) | 2500 |
| Paving Way | scraper blade paving |
| Paving Thickness (mm) | 30-200 |
| Boom Motor | High torque hydraulic motor |
| Vibrating System control | Vibrating motor |
| Exciting force (kg) | 100 |
| Vibrational Frequency (hz) | 50 |
| Laser System Control Type | Laser Scanning + High Sensitivity DC Push road |
| Laser System Control Effect | Flat surface, slope Floor |
| Driving System | Hydraulic driving tyre |
| Wheel | Heavy-duty tyre |
| Walking Speed (km/h) | 0-2.5 |
| Forward/backward | Switch Control, Stepless speed |
| Turing | Switch Control |
| Dimension (mm) | 3155×3175×1910 |
| Weight (kg) | 865 |
Specifications as published in the Topall Impex catalogue. Configurations can vary — confirm with our team before ordering.
Topall se LS-400 purchase karne ka experience professional raha. Machine commissioning, operator training aur subsequent support sab organised tha. Large concrete pours ke liye strong option laga.
Machine ki productivity large projects mein genuinely noticeable hai. Operator team ko training ke baad operation smooth laga.
Floor flatness requirement strict thi, isliye laser levelling machine choose ki. LS-400 ne work ko much more systematic bana diya.
Large warehouse slab ke liye machine ka performance impressive raha. Paving width ki wajah se ek pass mein kaafi area cover ho gaya.
LS-400 advanced equipment hai aur operator ko proper training zaroori hai. Topall commissioning ke time team ne setup explain kiya, jisse transition easy hua.
Machine ka stand-on operation long projects mein practical laga. Large concrete floor areas par productivity clearly better hui.
LS-400 large slab projects ke liye liya tha aur iska working width kaafi useful raha. Large pour mein coverage improve hua aur levelling process controlled raha.
